Download Catalog| Size | Item Code | Size (Tube OD) (mm) | Size(Thread)(R) | Price (per pc) |
|---|---|---|---|---|
| 4mm x 1/8" | CDCPCF0401 | 4 | Rc1/8 | 114 |
| 6mm x 1/8" | CDCPCF0601 | 6 | Rc1/8 | 123 |
| 6mm x 1/4" | CDCPCF0602 | 6 | Rc1/4 | 133 |
| 6mm x 3/8" | CDCPCF0603 | 6 | Rc3/8 | 151 |
| 6mm x 1/2" | CDCPCF0604 | 6 | Rc1/2 | 227 |
| 8mm x 1/8" | CDCPCF0801 | 8 | Rc1/8 | 159 |
| 8mm x 1/4" | CDCPCF0802 | 8 | Rc1/4 | 210 |
| 8mm x 3/8" | CDCPCF0803 | 8 | Rc3/8 | 210 |
| 8mm x 1/2" | CDCPCF0804 | 8 | Rc1/2 | 234 |
| 10mm x 1/4" | CDCPCF1002 | 10 | Rc1/4 | 176 |
| 10mm x 3/8" | CDCPCF1003 | 10 | Rc3/8 | 222 |
| 10mm x 1/2" | CDCPCF1004 | 10 | Rc1/2 | 240 |
| 12mm x 1/4" | CDCPCF1202 | 12 | Rc1/4 | 237 |
| 12mm x 3/8" | CDCPCF1203 | 12 | Rc3/8 | 245 |
| 12mm x 1/2" | CDCPCF1204 | 12 | Rc1/2 | 293 |
Male Connector (CDCPC)
Price range: ₹81.00 through ₹487.00
Male Elbow (CDCPL)
Price range: ₹102.00 through ₹496.00
Female Connector (CDCPCF)
Price range: ₹114.00 through ₹293.00
CDC Female Connector (CDCPCF)
CDC Standard One-Touch Push Fittings “CDC Series” offer a reliable and convenient solution for quick connections in pneumatic and fluid systems. Engineered for easy installation without the need for tools, these fittings ensure leak-proof performance and durability in various applications.
These fittings are used to create quick connections in pneumatic systems, facilitate efficient fluid transfer, enable easy assembly and disassembly of equipment, connect air supply lines in tools, and simplify the setup of automation systems.
| Type | CDCPCF |
| Applicable Fluid Type | Air (No other type of gas or liquid) |
| Working Pressure Range | 0-0.99 Mpa (0-10 bar) |
| Negative Pressure | -750 Torr / -750mm Hg |
| Working Temperature | 0-60°C |
| Applicable Tubing | PU Tube, Nylon Tube |
Please select the item size (Qty – Pcs)
Description
Reviews (0)
FAQs
A. It connects a tube to a threaded port in pneumatic systems, ensuring a secure and leak-proof joint.
A. Yes, the one-touch push-in design allows fast, tool-free installation.
A. Compatible with PU (Polyurethane) and Nylon tubes.
A. CDC fittings are engineered for high reliability and superior performance, suitable for demanding pneumatic applications, unlike standard or budget options.
A. Working pressure up to 0.99 MPa (10 bar) and negative pressure up to -750 Torr (-750 mm Hg).
